SINOFUSE EV315-L-3EB40A EV315 Series EV Power Fuse, 40A, 500VDC
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE EV315-L-3EB40A is a high-performance electric vehicle power fuse engineered for robust short-circuit, overload, and backup protection in demanding automotive and energy storage applications. Designed with a bottom-out structure for secure M5 bolt installation, this 40A, 500VDC fuse ensures reliable circuit interruption with a 20kA breaking capacity. It is fully RoHS compliant and optimized for electric vehicle drive systems, power converters, and battery storage systems.
| Product ID (MPN) | EV315-L-3EB40A |
| Rated Voltage | 500 VDC |
| Rated Current | 40 A |
| Breaking Capacity | 20 kA DC (Time Constant: 2±0.5ms) |
| Pre-arcing I²t | 748 A²s |
| Clearing I²t | 2306 A²s |
| Power Dissipation | 8 W |
| Size Code | L-3EB |
| Dimensions | Overall Length: 65.5±0.8mm, Mounting Pitch: 53.5±0.5mm, Hole Diameter: 10.3±0.2mm |
| Installation Remarks | Bottom Out Structure M5 Bolt, Torque: 4.5±1 N·m |
| Color Code | Orange |
| Weight | 12±1 g |
