SINOFUSE EV315-L-3EB60A EV315 Series EV Power Fuse, 60A, 500VDC
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE EV315-L-3EB60A is a high-capacity electric vehicle power fuse designed for superior short-circuit and overload protection in high-current automotive power systems. Featuring a compact L-3EB size with a bottom-out bolt-down structure, this 60A, 500VDC fuse provides a 20kA breaking capacity, making it ideal for EV drive power, battery storage, and heavy-duty charging systems. It is engineered for high-reliability performance and is fully RoHS compliant.
| Product ID (MPN) | EV315-L-3EB60A |
| Rated Voltage | 500 VDC |
| Rated Current | 60 A |
| Breaking Capacity | 20 kA DC (Time Constant: 2±0.5ms) |
| Pre-arcing I²t | 2100 A²s |
| Clearing I²t | 6500 A²s |
| Power Dissipation | 12 W |
| Size Code | L-3EB |
| Dimensions | Overall Length: 65.5±0.8mm, Mounting Pitch: 53.5±0.5mm, Hole Diameter: 10.3±0.2mm |
| Installation Remarks | Bottom Out Structure M5 Bolt, Torque: 4.5±1 N·m |
| Color Code | Black |
| Weight | 12±1 g |
