Sinofuse EV315-M-3E30A EV315 500VDC Series Road Vehicle Bolt-Connected Fuse, 500VDC, 30A
Regular price
$12.00 USD
Regular price
Sale price
$12.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-3E30A is a high-performance bolt-connected fuse designed specifically for road vehicle electrical systems, providing robust protection for EV power batteries, DC/DC converters, and auxiliary circuits. Engineered to withstand extreme temperature shocks and mechanical vibrations, this fuse ensures reliable overcurrent and short-circuit protection in demanding automotive environments in compliance with JASO D622 and ISO8820 standards.
| Product ID (MPN) | EV315-M-3E30A |
| Series | EV315 Series (M-3E) |
| Rated Voltage | 500VDC |
| Rated Current | 30A |
| Breaking Capacity | DC 20kA (Time Constant: 2±0.5ms) |
| I²t (total clearing) | 1025 A²s |
| Power Loss | 6W |
| Mounting Type | Bolt-Connected (Center Bolt Structure) |
| Tightening Torque | 4.5 ± 1N·m (M5 Bolt) |
| Color Code | Green |
| Weight | 14 ± 1g |
| Standards | JASO D622, ISO8820, GB/T31465, RoHS compliant |
