Sinofuse EV315-M-5M-100A Electric Vehicle Fuse, 100A 500V DC, High-Speed Bolt-on
Regular price
$25.00 USD
Regular price
Sale price
$25.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-100A is a high-speed DC fuse designed for main circuit protection in electric and hybrid electric vehicles. Its 100A rating and 500V DC interrupting capacity deliver rapid fault clearance for sensitive power electronics. Bolt-on terminals ensure reliable electrical contact under vibration and thermal cycling.
| Product ID (MPN) | EV315-M-5M-100A |
| Current Rating | 100 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 1600 A²s |
| Total Clearing I²t | 5200 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 15.0 W |
| Mounting Type | Bolt-on (Screw fixation) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, GB/T 31465, RoHS |
| Application | EV Main circuits, PDU, and battery energy storage protection |
