Sinofuse EV315-M-5M-125A Electric Vehicle Fuse, 125A 500V DC, High-Speed Bolt-on
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-125A is a high-speed DC fuse engineered for main circuit protection in electric and hybrid electric vehicles. Rated at 125A and 500V DC, it rapidly clears faults to safeguard power semiconductors and battery systems. Its bolt-on design provides vibration-resistant, low-resistance contact for reliable automotive operation.
| Product ID (MPN) | EV315-M-5M-125A |
| Current Rating | 125 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 2500 A²s |
| Total Clearing I²t | 8500 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 18.0 W |
| Mounting Type | Bolt-on (Screw fixation) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, GB/T 31465, RoHS |
| Application | EV Main circuits, DC charging piles, and battery pack protection |
