Sinofuse EV315-M-5M-150A Electric Vehicle Fuse, 150A 500V DC, High-Speed Bolt-on
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-150A is a high-speed DC fuse purpose-built for main circuit protection in electric and hybrid electric vehicles. With a 150A rating and 500V DC interrupting capacity, it rapidly clears faults to safeguard sensitive power semiconductors and battery modules. Its bolt-on design ensures reliable mechanical and electrical integrity in high-vibration automotive environments.
| Product ID (MPN) | EV315-M-5M-150A |
| Current Rating | 150 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 4200 A²s |
| Total Clearing I²t | 14200 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 22.0 W |
| Mounting Type | Bolt-on (Screw fixation) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, GB/T 31465, RoHS |
| Application | EV/HEV power circuits, motor controllers, and DC charging systems |
