Sinofuse EV315-M-5M-225A Electric Vehicle Fuse, 225A 500V DC, High-Speed Bolt-on
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-225A is a high-capacity, high-speed fuse engineered for main battery protection and power distribution in electric and hybrid electric vehicles. Its 225A continuous rating and 500V DC interrupting capability deliver rapid fault clearance to protect costly power semiconductors and energy storage modules. A bolt-down mounting interface ensures consistent low-resistance contact under severe vibration and thermal cycling.
| Product ID (MPN) | EV315-M-5M-225A |
| Current Rating | 225 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 10500 A²s |
| Total Clearing I²t | 35000 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 35.0 W |
| Mounting Type | Bolt-on (Screw fixation) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, UL 248-20, RoHS |
| Application | EV Main battery protection, PDU, and high-power inverter protection |
