Sinofuse EV315-M-5M-275A Electric Vehicle Fuse, 275A 500V DC, High-Speed Bolt-on
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-275A is a high-speed DC fuse engineered for critical main circuit protection in electric and hybrid electric vehicles. Rated at 275A continuous current and 500V DC, it rapidly clears faults to safeguard power semiconductors and battery systems. Bolt-down terminals ensure vibration-resistant, low-resistance contact for demanding automotive environments.
| Product ID (MPN) | EV315-M-5M-275A |
| Current Rating | 275 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 18000 A²s |
| Total Clearing I²t | 61500 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 44.0 W |
| Mounting Type | Bolt-on (Screw fixation) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, UL 248-20, RoHS |
| Application | Battery Management Systems (BMS), PDU, Main Motor Drive Protection |
