Sinofuse EV315-M-5M-350A EV315 High-Speed DC Fuse, 350A, 500V DC
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5M-350A is a high-speed DC fuse engineered for main battery and traction inverter protection in electric and hybrid electric vehicles. Rated at 350A and 500V DC, it delivers rapid fault clearance to protect power semiconductors and energy storage modules. Bolt-on terminals ensure vibration-resistant, low-resistance contact in demanding automotive environments.
| Product ID (MPN) | EV315-M-5M-350A |
| Current Rating | 350 A |
| Voltage Rating | 500 V DC |
| Interrupting Rating (Breaking Capacity) | 20 kA @ 500 V DC |
| Pre-arcing I²t | 39000 A²s |
| Total Clearing I²t | 133000 A²s (@ 500 V DC) |
| Power Dissipation (Loss) | ≤ 55.0 W |
| Mounting Type | Bolt-on (M-5M) |
| Operating Temperature Range | -40°C to +125°C |
| Standards Compliance | ISO 8820, JASO D622, UL 248-20, RoHS |
| Application | Traction Battery Protection, High-Power Inverters, EV Charging Infrastructure |
