Sinofuse EV315-M-5N350A EV315 Series Bolt-Connected Fuse, 500 VDC, 350 A
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-M-5N350A is a bolt-mounted DC fuse for road vehicle electrical systems, including electric vehicle drive power systems, power conversion systems, energy storage, traction batteries, chargers, and vehicle wiring protection. This EV315 Series fuse provides short-circuit, overload, and backup protection with verified 500 VDC and 350 A ratings for technical procurement and maintenance sourcing.
| Product ID (MPN) | EV315-M-5N350A |
| Series | EV315 |
| Product Category | Bolt-Mounted Automotive DC Fuse |
| Rated Voltage | 500 VDC |
| Rated Current | 350 A |
| Breaking Capacity | 20 kA for 100 A to 500 A ratings |
| Time Constant | 2 ± 0.5 ms |
| Pre-Arcing I²t | 36,117 A²s |
| Total Clearing I²t | 94,437 A²s |
| Power Loss | 59.5 W |
| Size Code | M-5N |
| Connection Structure | Middle bolt connection structure |
| Mounting Bolt | M10 |
| Recommended Torque | 21 N·m |
| Overall Length | 103 ± 2 mm |
| Body Diameter | 37.8 ± 0.5 mm |
| Terminal Thickness | 2.4 ± 0.2 mm |
| Normal Ambient Temperature | -5°C to 40°C |
| Allowable Ambient Temperature | -40°C to 120°C |
| Reference Standards | Performance reference JASO D622; environmental reliability conforms to ISO 8820, JASO D622, and GB/T 31465 |
| Compliance | RoHS compliant |
| Recommended Continuous Current | Not greater than 80% of rated current |
