SINOFUSE EV322-3EL-16A EV322 Series Road Vehicle Bolt-On Fuse, 700VDC, 16A, I²t 2311 A²s
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The SINOFUSE EV322-3EL-16A is a compact, low-power consumption, bolt-on fuse designed specifically for road vehicle applications, including electric vehicles. It offers high breaking capacity (50kA) and is engineered to withstand harsh environmental conditions such as temperature shock, vibration, and current surges. This fuse provides reliable short-circuit and overload protection for EV drive systems, power converters, battery packs, and charging circuits.
Key Features:
- Designed for road vehicles, compliant with JASO D622, ISO 8820, GB/T 31465 standards.
- High breaking capacity: 50kA at 700VDC (L/R < 10ms).
- Compact size and low power dissipation for space-constrained vehicle applications.
- Robust construction to endure strong temperature shocks, mechanical vibration/impact, and chemical loads.
- CE and RoHS compliant.
- Features a lower bolt connection structure (3EL) for specific mounting configurations.
| Product ID / MPN | EV322-3EL-16A |
| Brand | SINOFUSE |
| Series | EV322 |
| Type | Road Vehicle Bolt-On Fuse |
| Rated Voltage | 700 VDC |
| Rated Current | 16 A |
| Breaking Capacity (Icn) | 50 kA (L/R < 10ms) |
| I²t (Pre-arcing) | 2311 A²s |
| Power Dissipation | 2.9 W |
| Connection Type | Lower Bolt Connection (3EL) |
| Mounting Bolt | M5 |
| Installation Torque | (4.0 ± 0.8) N.m |
| Dimensions (L x W x H) | Approx. 65mm x 38mm x 54.4mm (See datasheet for exact tolerances) |
| Standards | JASO D622, ISO 8820, GB/T 31465, CE, RoHS |
| Operating Temperature | -40°C to +120°C (Derating required above +40°C) |
| Storage Temperature | -40°C to +70°C |
