Sinofuse EV323-2GL100A EV323-2GL DC Automotive Fuse, 100A, 250VDC
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV323-2GL100A is a high-performance DC automotive fuse engineered for 250VDC systems, delivering a robust 30kA breaking capacity. Designed for electric vehicle drive power, energy storage, and power conversion applications, it ensures reliable short-circuit and overload protection in a compact, low‑power‑dissipation form factor. Featuring a bottom‑out bolted M6 connection and RoHS compliance, it is an ideal choice for demanding automotive and industrial environments.
| Product ID (MPN) | EV323-2GL100A |
| Rated Voltage | 250 VDC |
| Rated Current | 100 A |
| Size Code | 2GL |
| Overall Length | 56±2 mm |
| Mounting Pitch | 41±3 mm |
| Rated Breaking Capacity | 30 kA (Time Constant: L/R ≤7 ms) |
| Pre-arcing I²t | 1586 A²s |
| Clearing I²t | 7979 A²s |
| Power Dissipation | 13 W |
| Installation | Bottom Out Bolted Structure M6, Recommended Torque: 6 N·m |
| Applications & Compliance | Electric Vehicle Drive Power Systems, Power Conversion Systems, Energy Storage and Power Batteries, Energy Storage Capacitors, Frequency Conversion Controllers, Chargers. Short‑circuit, overload and backup protection. RoHS Compliant. |
