Sinofuse EV323-2GL40A EV323-2GL DC Automotive Fuse, 40A, 250VDC
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV323-2GL40A is a compact, high‑performance DC automotive fuse engineered for 250VDC systems and rated to break 30kA. It is designed for electric vehicle drive power, energy storage, and power conversion applications, providing reliable short‑circuit and overload protection with low power dissipation. Featuring a bottom‑out bolted M6 connection and RoHS compliance, it is a robust solution for demanding automotive and industrial environments.
| Product ID (MPN) | EV323-2GL40A |
| Rated Voltage | 250 VDC |
| Rated Current | 40 A |
| Size Code | 2GL |
| Overall Length | 56±2 mm |
| Mounting Pitch | 41±3 mm |
| Rated Breaking Capacity | 30 kA (Time Constant: L/R ≤7 ms) |
| Pre‑arcing I²t | 176 A²s |
| Clearing I²t | 886.5 A²s |
| Power Dissipation | 5.5 W |
| Installation | Bottom Out Bolted Structure M6, Recommended Torque: 6 N·m |
| Applications & Compliance | Electric Vehicle Drive Power Systems, Power Conversion Systems, Energy Storage and Power Batteries, Energy Storage Capacitors, Frequency Conversion Controllers, Chargers. Short‑circuit, overload and backup protection. RoHS Compliant. |
