Sinofuse EV323-2GL63A EV323-2GL DC Automotive Fuse, 63A, 250VDC
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV323-2GL63A is a high‑performance DC automotive fuse engineered for 250VDC systems, delivering a robust 30kA breaking capacity. Designed for electric vehicle drive power, energy storage, and power conversion applications, it ensures dependable short‑circuit and overload protection in a compact, low‑power‑dissipation form factor. Its bottom‑out bolted M6 connection and RoHS compliance make it ideal for demanding automotive and industrial installations.
| Product ID (MPN) | EV323-2GL63A |
| Rated Voltage | 250 VDC |
| Rated Current | 63 A |
| Size Code | 2GL |
| Overall Length | 56±2 mm |
| Mounting Pitch | 41±3 mm |
| Rated Breaking Capacity | 30 kA (Time Constant: L/R ≤7 ms) |
| Pre‑arcing I²t | 540 A²s |
| Clearing I²t | 2715 A²s |
| Power Dissipation | 7.9 W |
| Installation | Bottom Out Bolted Structure M6, Recommended Torque: 6 N·m |
| Applications & Compliance | Electric Vehicle Drive Power Systems, Power Conversion Systems, Energy Storage and Power Batteries, Energy Storage Capacitors, Frequency Conversion Controllers, Chargers. Short‑circuit, overload and backup protection. RoHS Compliant. |
