Sinofuse EV323-2GL80A EV323-2GL Series DC Fuse, 80A, 250VDC
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV323-2GL80A is a robust, high‑speed DC fuse engineered for electric vehicle drive systems, energy storage, power conversion, and charger infrastructure. With a 250 VDC rating and a 30 kA breaking capacity, it delivers dependable short‑circuit and overload protection. The compact 2GL form factor and M6 bolted connection ensure low power loss and straightforward integration in demanding industrial environments.
| Product ID (MPN) | EV323-2GL80A |
| Rated Voltage | 250 VDC |
| Rated Breaking Capacity | 30 kA (Time Constant: L/R ≤ 7 ms) |
| Rated Current | 80 A |
| Pre‑arcing I²t | 959 A²s |
| Clearing I²t | 4827 A²s |
| Power Dissipation | 11 W |
| Size Code | 2GL |
| Overall Length | 56 ± 2 mm |
| Mounting Pitch | 41 ± 3 mm |
| Installation | Bottom‑out bolted structure, M6 threads, recommended tightening torque 6 N·m |
| Applications | EV drive power systems, energy storage, power conversion, frequency converters, chargers – short‑circuit, overload and backup protection |
| Compliance | RoHS |
