Sinofuse EV325-3EC50A EV325 Series EV Fuse, 50A, 750V DC
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Sinofuse EV325-3EC50A is a compact 750 V DC EV fuse designed for electric vehicle propulsion and other high-energy DC protection points. Its 50 A rating, 20 kA interrupting capacity, and round-cap 3EC construction help procurement teams specify a reliable overcurrent protection device for demanding mobility and energy-storage systems.
| Product ID (MPN) | EV325-3EC50A |
| Rated Current | 50 A |
| Rated Voltage | 750 V DC |
| Breaking Capacity | 20 kA at 750 V DC (L/R = 2 ± 0.5 ms) |
| Pre-Arcing I²t | 888 A²s |
| Total Clearing I²t | 5,204 A²s |
| Power Loss | 8.0 W |
| Size Code | 3EC |
| Dimensions / Size | 38 ± 0.6 mm length × 10.3 ± 0.1 mm diameter |
| Mounting / Style | Round cap style |
| Applications / Core Features | Road vehicles, electric vehicle drive power systems, power conversion systems, energy storage and power batteries, energy storage capacitors, frequency conversion controllers, chargers |
