SINOFUSE EV325-5FL20A EV325 Series Automotive Fuse, DC 750 V, 20 A
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE EV325-5FL20A is a DC 750 V automotive fuse designed for EV and high-voltage vehicle circuit protection. This 5FL-size fuse supports 20 A rated current with defined I²t performance, power-loss values, and M5 bolted mounting requirements for procurement and technical matching.
| Product ID (MPN) | EV325-5FL20A |
| Voltage Rating | DC 750 V |
| Rated Current | 20 A |
| Pre-arc I²t | 234 A²s |
| Total Clearing I²t | 588 A²s |
| Power Loss at 0.5In | 0.78 W |
| Power Loss at In | 3.9 W |
| Fuse Size | 5FL |
| Weight | 31.8±2 g |
| Minimum Breaking Current | 24 A |
| Maximum Breaking Current | 384 A |
| Compliance | RoHS compliant |
| Mounting Note | Mounting bolt M5; recommended torque 4.5±1.0 N·m |
