SINOFUSE FGB-A-3E6A FGB-A 3E Cylindrical Fast Fuse, AC 690 V, 6 A
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE FGB-A-3E6A is a cylindrical fast fuse designed for semiconductor protection in industrial electrical circuits. It is rated for AC 690 V and 6 A operation, with 100 kA breaking capacity for controlled fault protection in compatible fuse holder assemblies.
| Product ID (MPN) | FGB-A-3E6A |
| Rated Voltage | AC 690 V |
| Rated Current | 6 A |
| Rated Frequency | 45–62 Hz |
| I²t Pre-Arcing | 29 A²s |
| I²t Clearing | 140 A²s |
| Power Loss | 1.5 W |
| Breaking Capacity | 100 kA, cosφ > 0.2 |
| Protection Class | gG |
| Size Code | 3E |
| Dimensions | Diameter 10.3 mm; length 38 ±0.6 mm; end cap length 9.5 ±0.5 mm |
| Fuse Type | Cylindrical fast fuse for semiconductor protection |
| Compliance | IEC 60269; CE; RoHS |
| Mounting | TSA1038 series fuse holder or dedicated copper card holder |
| Remarks | Compatible with TSA1038 fuse holder |
