SINOFUSE RS306-01-S5P-50A1250V-D RS306 High Speed Fuse, 50A, 1250VAC/1000VDC
Regular price
$70.00 USD
Regular price
Sale price
$70.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-01-S5P-50A1250V-D is a high-speed bolt-on fuse optimized for the protection of power semiconductors, traction systems, and industrial converters. Built in a compact Size 01 form factor with specialized S5P termination, this fuse offers ultra-fast clearing of short-circuit currents and is equipped with a standard indicator base for real-time status monitoring in critical power circuits.
| Product ID (MPN) | RS306-01-S5P-50A1250V-D |
| Body Size | Size 01 |
| Rated Current | 50A |
| Voltage Rating | AC 1250V (IEC) / DC 1000V (UL) |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 140 A²s |
| Total Clearing I²t (Melt) | 1050 A²s |
| Power Loss | 15 W |
| Mounting Bolt | M8 Bolt (10N.m torque) |
| Configuration | Includes Indicator Base (-D) |
