SINOFUSE RS306-01-T5Z-200A1250V RS306 High Speed Fuse, 200A, 1250VAC/1000VDC
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-01-T5Z-200A1250V is a specialized high-speed bolt-on fuse tailored for the protection of power semiconductors and industrial energy systems. Featuring a compact Size 01 form factor and engineered for extreme reliability in traction and rail applications, this fuse provides ultra-fast short-circuit clearing and low power loss to maximize energy efficiency and component safety.
| Product ID (MPN) | RS306-01-T5Z-200A1250V |
| Product Series | RS306 High Speed |
| Body Size | Size 01 |
| Rated Current | 200A |
| Rated Voltage | AC 1250V (IEC) / DC 1000V (UL) |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 5090 A²s |
| Total Clearing I²t | 35800 A²s |
| Power Loss | 53 W |
| Mounting Bolt | M8 Bolt (11N.m torque) |
| Indicator Config | Indicator Model Case |
