SINOFUSE RS306-1-S5P-400A1250V-D RS306 High Speed Fuse, 400A, 1250VAC/1000VDC
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-1-S5P-400A1250V-D is a high-performance ultra-fast acting fuse designed for the protection of power semiconductors and heavy-duty industrial energy systems. Featuring a Size 1 body with a specialized S5P bolt-on termination, this fuse is engineered for extreme reliability in traction and rail applications, including a standard indicator base for real-time visual status monitoring in critical circuits.
| Product ID (MPN) | RS306-1-S5P-400A1250V-D |
| Product Series | RS306 High Speed (S5P) |
| Body Size | Size 1 |
| Rated Current | 400A |
| Voltage Rating | AC 1250V (IEC) / DC 1000V (UL) |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 29000 A²s |
| Total Melting I²t | 230000 A²s |
| Power Loss | 75 W |
| Mounting Bolt | M8 Bolt (10N.m torque) |
| Configuration | Includes Indicator Base (-D) |
