SINOFUSE RS306-1-T5Z-160A1250V-D RS306 High Speed Fuse, 160A, 1250VAC/1000VDC
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-1-T5Z-160A1250V-D is a high-performance high-speed fuse designed for the protection of power semiconductors and heavy-duty industrial electronics. Engineered for reliability in traction systems, power converters, and energy storage applications, this Size 1 fuse features a robust design capable of withstanding the demanding cycles of rail and road transportation environments.
| Product ID (MPN) | RS306-1-T5Z-160A1250V-D |
| Series | RS306 High Speed |
| Body Size | Size 1 |
| Rated Current | 160A |
| Voltage Rating (IEC) | AC 1250V |
| Voltage Rating (UL) | DC 1000V |
| Utilization Category | aR (UL) |
| Interrupting Rating | AC 100kA / DC 50kA (L/R=10~15ms) |
| Pre-arc I²t | 1850 A²s |
| Total Clearing I²t (Melt) | 15000 A²s |
| Power Loss | 45 W |
| Mounting Method | M10 Bolt / 21N.m Torque |
| Standard Compliance | IEC60269, UL248, GB/T 31465, CE, RoHS |
