SINOFUSE RS306-1-T5Z-630A1100V-D RS306 High Speed Fuse, 630A, 1100VAC/800VDC
Regular price
$100.00 USD
Regular price
Sale price
$100.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-1-T5Z-630A1100V-D is a high-capacity ultra-fast acting fuse engineered for the protection of high-power semiconductor devices and industrial rectification systems. Due to its high current rating, this Size 1 model features a specialized derated voltage profile to ensure safe interrupting performance in demanding traction, power storage, and heavy industrial converter applications.
| Product ID (MPN) | RS306-1-T5Z-630A1100V-D |
| Body Size | Size 1 |
| Rated Current | 630A |
| Voltage Rating (Derated) | AC 1100V / DC 800V |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 128000 A²s |
| Total Melt I²t | 658000 A²s |
| Power Loss | 100 W |
| Mounting Bolt | M10 Bolt (21N.m torque) |
| Indicator Type | Indicator Base Included (-D) |
