SINOFUSE RS306-2-J5P-1000A1100V-D RS306 High Speed Fuse, 1000A, 1100VAC/800VDC
Regular price
$100.00 USD
Regular price
Sale price
$100.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-2-J5P-1000A1100V-D is a high-capacity ultra-fast acting fuse designed for the protection of high-power semiconductor devices and industrial rectification systems. Utilizing a specialized J5P termination in a robust Size 2 body, this fuse is engineered for extreme reliability in heavy-duty traction and energy storage applications, featuring a derated voltage profile to ensure safe interrupting performance at maximum current levels.
| Product ID (MPN) | RS306-2-J5P-1000A1100V-D |
| Product Series | RS306 High Speed (J5P) |
| Body Size | Size 2 |
| Rated Current | 1000A |
| Voltage Rating (Derated) | AC 1100V / DC 800V |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 478000 A²s |
| Total Melting I²t | 2348000 A²s |
| Power Loss | 134 W |
| Mounting Bolt | M10 Bolt (15N.m torque) |
| Configuration | Includes Indicator Base (-D) |
