SINOFUSE RS306-2-S5P-500A1250V-D RS306 High Speed Fuse, 500A, 1250VAC/1000VDC
Regular price
$90.00 USD
Regular price
Sale price
$90.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS306-2-S5P-500A1250V-D is an ultra-fast acting high-speed fuse engineered for the protection of power semiconductors, industrial converters, and EV charging infrastructure. Built in a robust Size 2 body with a specialized S5P bolt-on mounting configuration, it provides exceptional reliability and low power loss in heavy-duty traction and energy storage applications, featuring an integrated indicator base for status monitoring.
| Product ID (MPN) | RS306-2-S5P-500A1250V-D |
| Product Series | RS306 High Speed (S5P) |
| Body Size | Size 2 |
| Rated Current | 500A |
| Voltage Rating | AC 1250V (IEC) / DC 1000V (UL) |
| Utilization Category | aR (High Speed) |
| Interrupting Rating | AC 100kA / DC 50kA |
| Pre-arch I²t | 47500 A²s |
| Total Clearing I²t (Melt) | 378500 A²s |
| Power Loss | 93 W |
| Mounting Bolt | M10 Bolt (15N.m torque) |
| Indicator Config | Indicator Base Included (-D) |
