SINOFUSE RS308-PV-3EA10A RS308-PV Series gPV Solar Fuse, 1000V AC/DC, 10A, Single Lead PCB Mount
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS308-PV-3EA10A is a specialized gPV cylindrical fuse featuring custom 3EA single-lead solder terminals for direct PCB integration in photovoltaic systems. Designed to protect DC circuitry up to 1000V, this 10A rated fuse provides critical high-speed overcurrent isolation for solar controllers and industrial PV power monitoring boards.
| Product ID (MPN) | RS308-PV-3EA10A |
| Series / Terminal Code | RS308-PV (3EA Single Lead) |
| Mounting Method | Direct PCB Solder (Single Lead) |
| Rated Current | 10A |
| Rated Voltage | 1000V AC / 1000V DC |
| Utilization Category | gPV (Photovoltaic) |
| Interrupting Rating | 10kA @ 1000V DC / 33kA @ 1000V AC |
| Power Dissipation | 2.1W |
| Melting I²t | 96 A²s |
| Body Dimensions | 10.3 x 39 mm |
