SINOFUSE RS308-PV-3EA12A RS308-PV Series gPV Solar Fuse, 1000V AC/DC, 12A, Single Lead PCB Mount
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS308-PV-3EA12A is a high-performance gPV cylindrical fuse featuring specialized 3EA single-lead solder terminals for direct integration onto printed circuit boards. Designed for photovoltaic system protection up to 1000V, this 12A rated fuse provides critical high-speed overcurrent isolation for PV controllers and automated solar power distribution units.
| Product ID (MPN) | RS308-PV-3EA12A |
| Series / Terminal Type | RS308-PV (3EA Single Lead) |
| Rated Current | 12A |
| Rated Voltage | 1000V AC / 1000V DC |
| Utilization Category | gPV (Photovoltaic) |
| Interrupting Rating | 10kA @ 1000V DC / 33kA @ 1000V AC |
| Power Dissipation | 2.4W |
| Melting I²t | 150 A²s |
| Body Dimensions | 10.3 x 39 mm |
