SINOFUSE RS308-PV-3EA2A RS308-PV Series gPV Solar Fuse, 1000V AC/DC, 2A, Single Lead PCB Mount
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS308-PV-3EA2A is a high-performance gPV cylindrical fuse featuring a specialized single-lead solder terminal designed for direct PCB mountain in solar photovoltaic systems. This 2A rated fuse provides critical high-voltage protection for sensitive control circuitry and small-scale strings in PV power systems operating up to 1000V.
| Product ID (MPN) | RS308-PV-3EA2A |
| Series / Size | RS308-PV (3EA Terminal) |
| Mounting Configuration | Single Lead Solder Tab (PCB) |
| Rated Current | 2A |
| Rated Voltage | 1000V AC / 1000V DC |
| Utilization Category | gPV (Photovoltaic) |
| Interrupting Rating | 10kA @ 1000V DC |
| Power Dissipation | 0.8W |
| Total Length | 39 mm (nominal) |
