SINOFUSE RS308-PV-3EA4A RS308-PV Series gPV Solar Fuse, 1000V AC/DC, 4A, Single Lead PCB Mount
Regular price
$10.00 USD
Regular price
Sale price
$10.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS308-PV-3EA4A is a specialized gPV cylindrical fuse featuring custom single-lead PCB mounting terminals for direct hardware integration. Designed to handle up to 1000V DC, this 4A rated fuse provides reliable high-speed circuit protection for photovoltaic control systems and industrial solar infrastructure, ensuring critical safety for sensitive electronic components.
| Product ID (MPN) | RS308-PV-3EA4A |
| Series / Terminal Type | RS308-PV (3EA Single Lead) |
| Mounting Method | Single PCB Lead Solder Terminal |
| Rated Current | 4A |
| Rated Voltage | 1000V AC / 1000V DC |
| Utilization Category | gPV (Photovoltaic) |
| Interrupting Rating | 10kA @ 1000V DC |
| Power Dissipation | 1.3W |
| Body Dimensions | 10.3 x 39 mm |
