Sinofuse RS309-MD-1000A RS309-MD Series High-Speed Fuse, 1000A, 500V AC/DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Sinofuse RS309-MD-1000A is a cylindrical bolt-connected high-speed fuse in the RS309-MD series, rated at 1000 A and 500 V AC/DC with an aR utilization category. The 1000 A variant uses size code 9RA and has a pre-arcing I²t of 180000 A²s, total clearing I²t of 570000 A²s, and rated power dissipation of 145 W.
| Manufacturer | Sinofuse |
| Model | RS309-MD-1000A |
| Series | RS309-MD |
| Fuse Type | Cylindrical bolt-connected high-speed fuse |
| Rated Current | 1000 A |
| Rated Voltage | 500 V AC/DC |
| Utilization Category | aR |
| Breaking Capacity | 200 kA AC; 50 kA DC, time constant ≤15 ms |
| Pre-Arcing I²t | 180000 A²s |
| Total Clearing I²t | 570000 A²s |
| Rated Power Dissipation | 145 W |
| Size Code | 9RA |
| Standards | UL 248, IEC 60269; safety and application-environment reliability according to ISO 8820 and GB/T 31465 |
| Compliance | CE, RoHS |
The manufacturer lists the RS309-MD series for electric-vehicle drive power systems, power-conversion systems, energy-storage and power systems, variable-frequency controllers, chargers, wiring, and other vehicle components and equipment requiring circuit protection.
Apexon Supply provides B2B sourcing and replacement support for Sinofuse RS309-MD-1000A. Buyers should verify the rated current, voltage, aR category, breaking capacity, I²t characteristics, and mounting requirements against the original equipment specification before replacement.
Send RS309-MD-1000A, required quantity, and application requirements for RFQ support and technical alignment. Most qualified RFQs receive a response or quote within 12 hours.
