SINOFUSE RS309-MD-500A RS309-MD Series High-Speed Fuse, 500A, 500VDC
Regular price
$45.00 USD
Regular price
Sale price
$45.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RS309-MD-500A is a robust cylindrical bolt-connected high-speed fuse optimized for the protection of high-power semiconductors. Engineered for electric vehicle (EV) drive systems, energy storage systems, and industrial power conversion, it provides rapid fault isolation with a 50kA DC breaking capacity and high thermal reliability under demanding mechanical conditions.
| Product ID (MPN) | RS309-MD-500A |
| Rated Voltage | 500VAC / 500VDC |
| Rated Current | 500A |
| Breaking Capacity | AC 200kA / DC 50kA (τ ≤ 15ms) |
| Utilization Category | aR |
| Size Code | 7ZB |
| Pre-arcing I²t | 48000 A²s |
| Total Clearing I²t | 178500 A²s |
| Rated Power Loss | 85W |
| Mounting Bolt | M10 (Recommended Torque 21±1N.m) |
| Standards | UL248, IEC60269, CE, TUV, RoHS |
