SINOFUSE RS309-MD-60A High-Speed Fuse, 60A, AC/DC 500V
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
SINOFUSE RS309-MD-60A is an RS309-MD Series round tube bolt-connected high-speed fuse rated 60A and AC/DC 500V. It is designed for high breaking capacity protection in industrial, vehicle power, power conversion, energy storage, drive, charger, conductor, and equipment protection applications.
| Product ID / MPN | RS309-MD-60A |
| Brand / Series / Category | SINOFUSE RS309-MD Series High-Speed Fuse |
| Rated Voltage | AC/DC 500V |
| Rated Current | 60A |
| Utilization Category | aR |
| Breaking Capacity | AC 200kA; DC 50kA, time constant ≤15ms |
| Pre-Arcing I²t | 280 A²s |
| Operating I²t | 870 A²s |
| Rated Power Dissipation | 10W |
| Size Code | 3XA |
| Mechanical Dimensions | A 81mm; B 20mm; C 40mm; D 55mm; E 65mm; F 9mm; G 15mm; H 3.3mm |
| Mounting / Terminal / Connection | Bolt-connected cylindrical fuse; M8 mounting bolt; recommended torque 12±1 N.m |
| Environmental Ratings | Normal ambient operating condition -5°C to 40°C; allowable operating condition -40°C to 120°C |
| Standards / Certifications | UL248; IEC60269; ISO8820; GB/T 31465; CE; UL; RoHS |
| Installation Notes | Recommended long-term current value should not exceed 80% of rated current |
This RS309-MD-60A fuse is typically used for short-circuit, overload, and backup protection in electric vehicle drive power systems, power conversion systems, energy storage and power systems, variable frequency controllers, chargers, conductors, and other vehicle-related devices and equipment.
Apexon Supply provides B2B sourcing and replacement support for SINOFUSE high-speed fuses using verified product identifiers, ratings, dimensions, and installation data for procurement teams, MRO buyers, and system integrators.
Send the MPN, required quantity, and application requirements to request a B2B quote and confirm sourcing options and technical alignment for this high-speed fuse.
