Sinofuse RSZ307-01-J4P-200A750V-N High-Speed DC Fuse, 750 VDC, 200 A
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse RSZ307-01-J4P-200A750V-N is a 200 A, 750 VDC high-speed DC fuse with an aR utilization category. The “-N” suffix identifies the version without an indicator.
| Manufacturer Part Number | RSZ307-01-J4P-200A750V-N |
| Rated Voltage | 750 V DC |
| Rated Current | 200 A |
| Utilization Category | aR (IEC) |
| Breaking Capacity | ≥50 kA at L/R = 5–10 ms |
| Pre-Arcing I²t | 11,200 A²s |
| Total Clearing I²t | 25,700 A²s |
| Power Loss | 40 W |
Specified for electric vehicle applications, this partial-range fuse can provide short-circuit overcurrent and backup protection in energy storage and power systems, conductors, and other equipment.
Contact Apexon Supply for B2B sourcing support, technical alignment, and replacement-part inquiries.
Request a quote for the Sinofuse RSZ307-01-J4P-200A750V-N. Include your required quantity and application details to support your RFQ.
