SINOFUSE RSZ307-1-TMZ-N 500A RSZ307 Series High-Speed Square Body Fuse, 500A, 250VDC
Regular price
$60.00 USD
Regular price
Sale price
$60.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SINOFUSE RSZ307-1-TMZ-N is a high-performance semiconductor protection fuse designed for high-power industrial applications. Engineered for the protection of DC power systems and power electronics components, this aR utilization class fuse provides rapid short-circuit response and high breaking capacity to ensure maximum safety for sensitive equipment.
| Product ID (MPN) | RSZ307-1-TMZ-N |
| Series | RSZ307 |
| Rated Current | 500A |
| Rated Voltage | 250VDC |
| Breaking Capacity (I1) | 50kA |
| Utilization Category | aR (Partial range semiconductor protection) |
| Resistance (20°C) | 0.125mΩ |
| Standards | IEC60269, UL248 |
| Certifications | cURus, TÜV, RoHS Compliant |
| Mounting Type | Blade / Bolt-on style |
