Sinofuse RSZ307-1-TMZ-N RSZ307 Series High Speed DC Fuse, 630A, 250VDC
Regular price
$75.00 USD
Regular price
Sale price
$75.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse RSZ307-1-TMZ-N is a high-capacity, high-speed semiconductor fuse designed for robust protection in DC power systems and electric vehicle infrastructure. With a 630A rating and aR characteristic, it provides ultra-fast clearing of short-circuit faults to protect power conversion equipment and battery arrays.
| Product ID (MPN) | RSZ307-1-TMZ-N |
| Rated Current | 630A |
| Rated Voltage | 250VDC |
| Utilization Category | aR (High Speed Semiconductor Protection) |
| Breaking Capacity | 50kA |
| Standards | IEC 60269, UL 248 |
| Certifications | TÜV, CE, RoHS |
