TDK-Lambda G600-8.5-3P400 GENESYS+ 5kW Series Programmable DC Power Supply, 0-600VDC, 0-8.5A
Regular price
$7,680.00 USD
Regular price
Sale price
$7,680.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The TDK-Lambda G600-8.5-3P400 is a high-performance 5.1kW programmable DC power supply from the advanced GENESYS+ series, engineered specifically for rigorous OEM, industrial, and laboratory applications. Delivering precision metrology and control with a 0 to 600VDC output range and up to 8.5A current capacity, this ultra-compact 1U rack-mount unit features active PFC for maximum energy efficiency. It ensures robust automated testing and system integration capabilities through its built-in LAN (LXI compliant), USB, RS-232, RS-485, and isolated analog control interfaces.
| Product ID (MPN) | G600-8.5-3P400 |
| Product Series | GENESYS+ (5kW Models) |
| Input Voltage | 342 to 460 VAC (3-Phase) |
| Input Frequency | 47 to 63 Hz |
| Rated Output Voltage | 0 to 600 VDC |
| Rated Output Current | 0 to 8.5 A |
| Rated Output Power | 5100 W |
| Efficiency | 92% Typ. |
| Voltage Ripple Noise | 0.1 Vrms (5Hz to 1MHz) |
| Current Ripple Noise | 0.004 Arms (5Hz to 1MHz) |
| Form Factor | 1U Rack Mount / Bench Top |
| Dimensions (W x H x D) | 423 mm x 43.6 mm x 441.5 mm |
| Built-In Interfaces | LAN (LXI 1.5), USB, RS-232, RS-485, Isolated Analog |
| Safety Compliance | IEC61010-1, CSA C22.2 No.61010-1, EN61010-1, UL61010-1 |
| Approvals | CE Mark, UKCA Mark, RoHS |
