ZP200A Thyristor (SCR) Control Tube, 200–2000V — Power Trigger Device (Pack of 10)

ZP200A Thyristor (SCR) Control Tube — 200–2000V — Pack of 10

Overview

• Part number: ZP200A
• Product: Thyristor / Silicon Controlled Rectifier (SCR) control tube
• Voltage indication: 200–2000 V
• Pack quantity: 10 pieces
• Intended use: Gate triggering and control in power-electronics and industrial control systems

Key features

• ZP200A thyristor control tube delivering reliable gate-trigger functionality for power control applications.
• Indicated operating voltage range: 200–2000 V — suitable for medium- to high-voltage circuits.
• Supplied in a pack of 10 for production, maintenance and spare stocking.
• Compact semiconductor device designed for integration into trigger modules, driver boards and power-control assemblies.

Typical applications

• Phase-angle control for AC power regulation (dimmers, heater controllers).
• Motor control, soft-start circuits and speed regulation.
• Trigger circuits for power supplies, inverters and DC/AC converters.
• Industrial automation and process-control systems requiring SCR triggering.

Handling & installation notes

• Observe ESD-safe handling procedures to prevent damage to the gate and junction.
• Verify package type, pinout and mechanical compatibility with your PCB or mounting hardware prior to installation.
• Confirm gate drive voltage, expected load current and thermal dissipation; provide appropriate heat sinking or mounting to maintain junction temperature within rated limits.
• Store in a dry, static-controlled environment until use.

Ordering & identification

• Part: ZP200A
• Voltage indication: 200–2000 V
• Pack size: 10 pieces
• Product family: Thyristors / SCR control tubes
