ZP50A Wired Thyristor (SCR) Control Tube, 200–2000V — Wired Gate Trigger Device (Pack of 10)

ZP50A Wired Thyristor (SCR) Control Tube — 200–2000V — Pack of 10

Overview

• Part number: ZP50A (wired)
• Product type: Thyristor / Silicon Controlled Rectifier (SCR) control tube with pre-attached gate lead
• Voltage indication: 200–2000 V
• Pack quantity: 10 pieces
• Intended use: Gate triggering and control in power-electronics and industrial control applications

Key features

• Wired SCR control tube with integrated gate lead for simplified connection and rapid installation
• Indicated voltage range 200–2000 V suitable for medium- to high-voltage control tasks
• Supplied as a pack of 10 for production use, maintenance, or spare inventory
• Compact power semiconductor device for integration into trigger circuits, driver modules and power-control assemblies

Typical applications

• Phase-angle control for AC power regulation (dimmers, heater controllers)
• Motor control, soft-start circuits and speed regulation
• Trigger circuits for power supplies, inverters and converters
• Industrial automation and process-control systems requiring SCR triggering

Handling & installation notes

• Observe ESD-safe handling procedures to prevent damage to gate/junction.
• Verify lead length, insulation and pinout compatibility with your PCB, socket or assembly prior to mounting.
• Confirm gate drive voltage, expected load current and thermal dissipation; provide appropriate heat sinking or mounting to maintain specified junction temperature.
• Store in a dry, static-controlled environment until installation.

Ordering & identification

• Part: ZP50A (wired)
• Voltage indication: 200–2000 V
• Pack size: 10 pieces
• Product family: Thyristors / Wired SCR control tubes
