Westcode 069UR2S1000B European Square Body Semiconductor Protection Fuse, 1000A, 690V AC
Regular price
$450.00 USD
Regular price
Sale price
$450.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Westcode 069UR2S1000B is an ultra-rapid semiconductor protection fuse designed for high-performance industrial power applications. Part of the European Square Body series with French Standard end contacts, this Size 2 fuse provides exceptional circuit protection with a 200kA interrupting rating and features an integrated trip-indicator for simplified system monitoring.
| Product ID (MPN) | 069UR2S1000B |
| Order Code | 069UR2S1000B |
| Rated Current (In) | 1000A |
| Rated Voltage (Un) | 690V AC |
| Tested Interrupting Rating | 200kA @ 690V |
| Utilization Category | aR (Ultra Rapid) |
| Pre-arcing I²t | 240 (10³ kA²s) |
| Total Clearing I²t @ Un | 1250 (10³ kA²s) |
| Power Loss (at In) | 135 W |
| Body Size | Size 2 |
| Fixing Type | French Standard End Contacts (S) |
| Indicator | Integrated Trip-Indicator (Type B) |
| Standards Compliance | IEC 60269-4, UL recognized, DIN, VDE |
